Ubiquiti UVC-G5-Dome IP security camera Indoor & outdoor 2688 x 1512 pixels Ceiling/wall
Ubiquiti UVC-G5-Dome IP security camera Indoor & outdoor 2688 x 1512 pixels Ceiling/wall
MPN UVC-G5-DOME
Item no. W128229897
EAN/UPC 810084690208
Stock level
Next-gen 2K HD PoE ceiling camera with enhanced dynamic range and low-light performance.
2K HD, 30 FPS camera with a 5MP CMOS sensor
Wide-angle view (102.4˚)
Weatherproof IPX4-rated enclosure with IK08-rated vandal resistance
Improved low-light performance and IR night vision up to 10m
Improved dynamic range
Specifications for UVC-G5-DOME
Audio
Built-in microphone
Yes
Built-in speaker(s)
Yes
Camera
Camera pan control
Yes
Lens viewing angle, diagonal
134.3 °
Lens viewing angle, horizontal
102.4 °
Lens viewing angle, vertical
71.4 °
Design
Form factor
Dome
Housing material
Aluminium, Polycarbonate (PC), Stainless steel
IK code
IK08
International Protection (IP) code
IPX4
Mounting type
Ceiling/wall
Product colour
White
Image sensor
Number of sensors
1
Sensor type
CMOS
Lens system
Number of lenses
1
Management features
Reset button
Yes
Network
Bluetooth
No
Ethernet interface type
Fast Ethernet
Ethernet LAN
Yes
Wi-Fi
No
Night vision
LED type
IR
Night vision
Yes
Night vision distance
10 m
Operational conditions
Operating relative humidity (H-H)
0 - 90 %
Operating temperature (T-T)
-20 - 40 °C
Package dimensions
Gross Weight (Package, kg)
0.4 kg
Packaging content
Cables included
LAN (RJ-45)
Mounting kit
Yes
Number of cameras
1
Performance
Built-in processor
Yes
Certification
FCC, IC, CE
Connectivity technology
Wired
Placement supported
Indoor & outdoor
Processor model
ARM Cortex-A7
Type
IP security camera
Ports & interfaces
Ethernet LAN (RJ-45) ports
1
Power
AC input voltage
37 - 57 V
Power consumption (typical)
5 Watt
Power source type
PoE
Product dimensions
Net Weight (Product, kg)
0.37 kg
Product Depth
6.42 cm
Storage
Built-in HDD
No
Vendor information
Brand Name
Warranty
2 Year(s)
Video
Frame rate
30 fps
Image quality adjustment
Brightness, Colour depth, Contrast, DNR
Maximum resolution
2688 x 1512 Pixels
Noise reduction
Yes
Noise reduction technology
3D noise reduction
Total megapixels
5 MP
Video compression formats
H.264, M-JPEG
Weight & dimensions
Diameter
10.92 cm
Description
Next-gen 2K HD PoE ceiling camera with enhanced dynamic range and low-light performance.
